QUINT-PS-100-240AC/24DC/5
DC OK Signal Output, Floating
Type of output
Continuous current
Maximum switching voltage
General Data
Insulation voltage
Input/output
Input/PE
Insulation voltage output/PE
Mounting position
Degree of protection
Protection class
MTBF
Housing version
Weight
Dimensions (width x height x depth)
Dimensions (width x height x depth) for alternative assembly
Status Indicators
DC OK status indicator
Climatic Data
Ambient temperature (operation)
Ambient temperature (storage/transport)
Maximum permissible humidity (operation)
Vibration (operation)
Shock
Pollution degree
Climatic class
Certification/Standards
Electrical equipment of machines
Safety transformers for switched-mode power supply units
Electrical safety (of IT equipment)
Industrial control equipment
Electrical equipment for potentially explosive areas
Shipbuilding
Electronic equipment for use in electrical power installations
Safety extra-low voltage
Safe isolation
Protection against electric shock
Protection against electric shock, basic requirements for safe isolation in
electrical equipment
Limitation of harmonic line currents
Device safety
Relay contact, U out > 0.9 x U N : Contact closed
1 A, maximum
30 V AC/DC, maximum
4 kV AC (type test)/2 kV AC (routine test)
3.5 kV AC (type test)/2 kV AC (routine test)
500 V DC (routine test)
On horizontal NS 35 DIN rail according to EN 60715
IP20
Ι , with PE connection
> 500,000 h according to IEC 61709 (SN 29500)
AluNox (AlMg1), closed
0.830 kg
55 mm x 130 mm x 125 mm
122 mm x 130 mm x 58 mm
Green LED (U out < 0.9 x U N : LED flashes)
-25...+70°C (> 60°C derating)
-40...+85°C
95% (at +25°C, no condensation)
< 15 Hz, amplitude ±2.5 mm according to IEC 60068-2-6
15...150 Hz, 2.3g, 90 minutes
30g in all space directions, according to IEC 60068-2-27
2 according to EN 50178
3K3 according to EN 60721
EN 60204 (Surge Voltage Category III)
EN 61558-2-17
EN 60950/VDE 0805 (SELV), EN 61558-2-17
CB Scheme j
LISTED
UL/C-UL Recognized UL 60950 u
UL/C-UL Listed UL 508 U
UL/C-UL Recognized UL 1604, Class Ι , Division 2, Groups A, B, C, D
Germanischer Lloyd F , ABS
EN 50178 (VDE 0160)
PELV (EN 60204), SELV (EN 60950)
DIN VDE 0100-410, DIN VDE 0106-1010
DIN 57100-410
DIN VDE 0106-101
According to EN 61000-3-2
B (tested safety)
100029_04_en
PHOENIX CONTACT
3
